Sic Rod Heating Element
Sic Rod Heating Element
Withstand temperatures up to 1400°C.
Coating surface is treated with good anti-oxidation and anti-corrosion.
Products Description
Sic Rod Heating Element is most widely used type in different electric furnaces with advantages of environmentally friendly and energy saving. It is actually a non-metallic heating element whose resistivity changes with the change of temperature. The main material is silicon carbide through a certain molding process, and sintered by ultra-high temperature. This Sic Rod Heating Element is mainly used in non-ferrous metal smelting, steel, metallurgical beneficiation and other industries.
Physical property of SIC heating element
| Bulk density | 2.6~2.8g/cm3 | BendStrength Tensile | ＞300kg |
| Hardness | ＞9MOH’S | strength | ＞150kg/cm³ |
| PorosityRate | ＜30% | Radiance | 0.85 |
Specifications
OD: 14mm-40mm Overall Length: 700mm-4300mm
The main factors that affect the service life of Sic Rod Heating Element
1. Working temperature. The shorter life under the higher temperature.
2. Surface load
the larger the surface load density(electric power) of the element, the higher temperature,the shorter life of the elements
3. The furnace operation mode
Silicon carbide rod in continuous furnace and intermittent furnace, the former longer life.
Q&A
1. What is the delivery time?
Generally, 10days within 300pcs order. 20days within 500pcs order.
2. What is the payment terms?
T/T, L/C, Credit card or as per your request.
